SKSK2_EN
| Cod Ean | 8595568919663 |
| Cod vamal | 85369010 |
| Greutate | 0,0360 kg/pcs |
| Material | PP |
| Material fără halogeni | yes |
| Cu suto-stingere | 30 s |
| Voltaj nominal | <= 500 V |
| Rezistența la temperatură | -40 - 85 °C |
| Testat cu buclă incinsă | 850 °C |
| Lătime | 104 mm |
| Înăltime | 30 mm |
| Sectiune mediană a conductorului conectat | 4 x 2,5 - 4; 3 x 6 mm2 |
| Clasa de reacţie la foc a materialului de fond | A1 - F |
| Descriere impachetare 10 pcs terminal plate wrapped in foil, marked with a label | |
Suitable for boxes KSK 125 and KSK 175. Branching terminal plate are composed of five separate terminals. Each terminal is intended for 4 wires of cross section 2.5 – 4 mm2 or 3 wires of cross section 6 mm2. Allows mounting to posts inside boxes or to the box bottom – installation is done using screws that are included. Designed for maximum voltage of 500 V. Tested according to ČSN EN 60998-1.
